DeckLink Studio includes highest quality 10 bit SDI video combined with enhanced analog connections to support a massive range of video equipment. DeckLink Studio includes fully independent connections for SDI, HDMI, analog component, S-Video and composite video. Both the SDI and analog component connections auto switch between SD and HD, plus there's an extra SD SDI output via a built in hardware down converter for when you're working in HD. When you're working in NTSC and PAL, you can use the SD-SDI output as a key output! Also included are a massive number of audio connections, with 4 channels of balanced analog audio, 8 channels of SDI audio plus 2 channels of AES/EBU digital with sample rate converters. For a broadcast strength solution, DeckLink Studio also has RS-422 deck control and blackburst and tri-sync reference input. DeckLink cards let you capture and playback to the widest range of equipment, such as HDCAM, HD-D5, HDCAM SR 4:2:2, Betacam SP, Digital Betacam, HD receivers, HDV cameras, televisions, VHS recorders, analog broadcast monitors, mixers and many more!
If you've ever wanted to monitor in both HD and SD while you work, then you'll love the built in high quality down converter on the DeckLink Studio model that's always active on the SD-SDI, S-Video and composite video output connections. This lets you use the main SD/HD-SDI output for HD, while simultaneously using the SD-SDI, S-Video and composite outputs for standard definition. When working in HD the built in down converter lets all video outputs remain active in both capture and playback mode, and in all HD video formats!
Re: Media Express download Fri Apr 24, 2015 6:33 am On the support page on the main BM website click on 'Capture and Playback' then on the left under 'latest downloads' download 'Desktop video 10.4' by clicking on the 'Mac OS X' button. Tipard Total Media Converter for Mac, universal DVD and video file Media Converter for Mac, can. The go Powerful Total Media Converter for Mac is. DVD to any portable media players or devices. 2.Convert video Tipard Total Media Converter for Mac owns.
You can instantly select between letterbox, anamorphic 16:9 and center cut 4:3 down conversion styles. DeckLink Studio includes enhanced analog connections to make it easy to connect to a wider range of analog broadcast equipment. You can simultaneously connect to analog component, S-Video and composite equipment, because DeckLink Studio has independent connections for each.
All outputs are always active and will output via the built in down converter when you're working in HD. DeckLink Studio is the perfect capture card for working with decks such as Betacam SP, as it includes 4 channels of balanced analog audio, so you can capture and playback all 4 channels of Betacam SP audio at the same time. DeckLink Studio has more analog connections than SD only capture cards and costs hundreds of dollars less!
DeckLink Studio features a massive 4 channels of balanced professional analog audio in and out, as well as 2 channels of AES/EBU digital audio in and out, for broadcast quality and sample accurate AV sync. DeckLink Studio also includes a sample rate converter on the AES/EBU input, so you can connect to any digital audio device, from either synchronized or un-synchronized sources. DeckLink Studio includes 8 channels of SDI embedded audio that are perfect for Final Cut Pro and Premiere Pro's multi channel audio support.
When working with multi channel audio, DeckLink Studio can switch it's analog audio output 3 and 4 to AES/EBU digital audio outputs. That means you get an extra 2 digital audio outputs for a total of 6 channels of AES/EBU digital audio out! DeckLink Studio is perfect for 5.1 surround sound editing and multi language digital audio monitoring. For highest quality digital broadcast workflows, DeckLink cards include incredible 10 bit SD/HD-SDI video with low SDI jitter, combined with AES/EBU digital audio with a high performance linear phase digital filtered sample rate converter.
Blackmagic Media Express Windows 10
DeckLink Studio features a total of 10 on board power supplies to isolate high precision analog electronics from digital noise, so you get pristine quality analog video and audio. Only DeckLink cards provides all the quality you need for the most demanding broadcast environments and ensures your work retains that wonderful film look! DeckLink's super fast PCI Express connection plugs directly into Final Cut Pro and Premiere Pro's real time effects processing engine. Unlike FireWire products, you get all your CPU time dedicated to more multi layer HD real time effects. Only DeckLink Studio's high speed PCI Express lets you upgrade to HD without limiting your HD real time effects! The higher speed of PCI Express easily handles both compressed and uncompressed video file formats, such as ProRes(Mac), DVCPro HD, JPEG, DV, HDV playback, uncompressed 8 bit and uncompressed 10 bit.
1 Lane PCI Express also allows DeckLink Studio to work in lower cost computers and is fully compatible with 1, 4, 8 and 16 lane PCI Express slots. When working in standard definition, DeckLink cards include the most amazing quality digital internal keyer that lets you key RGBA images over the video input. That's a total keying solution built right into DeckLink Studio. The built in keyer works great when used with Blackmagic Design's included Photoshop plug-ins, or even with RGBA animated video software for keying. If you want to perform keying externally, such as an external video mixer, then just select external key and DeckLink Studio will output the key channel on the SD-SDI output, with the fill channel on the main SD/HD-SDI output.
DeckLink cards are perfect for editing, broadcast graphics and digital effects work with built in support for your favorite video software such as Apple Final Cut Pro™, Adobe Premiere Pro™, Adobe After Effects™, Adobe Photoshop™, eyeon Fusion™ and many more. DeckLink includes plug ins for Photoshop so you can capture and output frames directly from within Photoshop. Real time playback from Adobe After Effects is supported so you can live preview your animations on your broadcast monitor. For ultimate flexibility, you can install on Windows XP™, Windows Vista™, Windows 7™ and Intel-based Mac Pro systems and instantly switch between 1080i, 1080p and 720p formats in HD, or NTSC and PAL formats for worldwide compatibility. DeckLink cards include the Media Express deck control software which lets you control a deck remotely via RS-422 for capture and playback of DPX, AVI and QuickTime™ clips with timecode accuracy. Media Express is supported on Mac OS X™, Windows™ and Linux™.
To help set up high speed disk arrays for uncompressed 10 bit HD editing, DeckLink includes Blackmagic Disk Speed Test™ software that checks your disk array and gives you an easy to understand speed test with the results in video frames per second! Blackmagic Media Express Blackmagic Media Express is free software that comes with every DeckLink card.
Media Express lets you batch capture and playback 2D or even dual stream stereoscopic 3D in uncompressed YUV and RGB QuickTime, AVI and DPX, or compressed ProRes, DVCPRO and MJPEG files. You can create your own playlist, organize clip bins and add additional metadata. Media Express is perfect for software applications that don't support direct capture and playback with tape decks from within the software itself.
Media Express supports XML and CMX EDL import and export, plus frame accurate deck control via RS-422. Media Express is a complete solution for capture and playback!. Playlist in Playback Mode You can load in a huge number of clips for review. Use DPX, MJPEG, uncompressed YUV and RGB, ProRes, DVCPRO HD all in the same playlist. Realtime Preview Preview your clips with full frame rate for accurate review. Audio Metering With Media Express you can select any of the 16 audio channels. Simply click on the audio you want to hear.
Black Magic Media Express Troubleshooting
Capture, Play or Master Capture on the fly. Play back single or multiple clips. Master to tape via insert or assemble editing. Dynamic Playlist Search Organizing your playlist has never been easier with Media Express' dynamic playlist search.
Even if you have 1,000 clips, you'll always find the right clip. Clip Information Now you can see all the important detail information of your clip, including frame size, frame rate, color space, format and codec. Easy Grab Frame Tool Media Express makes grabbing frames of your video easy. When the frame you want is displayed in the preview window, just hit Grab Frame.
(Fremont, California-July 25, 2012) Blackmagic Design today released a series of new software updates for its products that adds full support for Apple’s new Mac OS X 10.8 Mountain Lion operating system. These software updates include support for Apple’s new Gatekeeper anti malware security protection for all products, including DaVinci Resolve 9, Desktop Video products including DeckLink, Intensity, UltraStudio, H.264 Pro Recorder and Media Express, ATEM Switchers, UltraScope, Mini, Heavy Duty and Battery Converters, Videohub Routers, SmartView Monitors, HyperDeck Studio and Shuttle Disk Recorders, HDLink and Video Recorder.
Gatekeeper is a new security feature which protects your computer from downloading and installing malicious software. Blackmagic Design is one of the first companies to support this new security standard from the first day Mac OS X 10.8 Mountain Lion is available to customers. As an Apple Identified developer, when Gatekeeper is set to the default option, our customers will continue to be able to download software, easily maintaining full security protection. “Being an Apple Identified Developer has enabled Blackmagic Design to take full advantage of the many exciting new features in Mac OS X 10.8 Mountain Lion, such as Gatekeeper, right from the very first day of its release,” said Grant Petty, CEO, Blackmagic Design.
”Our customers can be assured that they will continue to be able to easily download our software and enjoy performance improvements when they upgrade to Mac OS X 10.8 and Blackmagic Design products.” These new software updates support all of Blackmagic Design’s products. Availability and Price The software updates are available now free of charge for all DeckLink, Intensity, UltraStudio, H.264 Pro Recorder, UltraScope, ATEM Switchers, Mini Converter, Heavy Duty Mini Converter, Battery Converter, Videohub and Universal Videohub routers, SmartView, HyperDeck, HDLink and Video Recorder customers from the Blackmagic Design web support page at.
About Blackmagic Design Blackmagic Design creates the world’s highest quality video editing products, digital film cameras, color correctors, video converters, video monitoring, routers, live production switchers, disk recorders, waveform monitors and film restoration software for the feature film, post production and television broadcast industries. Blackmagic Design’s DeckLink capture cards launched a revolution in quality and affordability, while the company’s DaVinci Emmy™ award winning color correction products have dominated the television and film industry since 1984. Blackmagic Design continues ground breaking innovations including stereoscopic 3D and 4K workflows.
Founded by world leading post production editors and engineers, Blackmagic Design has offices in the USA, UK, Japan, Singapore, and Australia. For more information, please check. '(Fremont, California-July 25, 2012) Blackmagic Design today released a series of new software updates for its products that adds full support for Apple’s new Mac OS X 10.8 Mountain Lion operating system.' I can't find any updates released today, just Resolve 8.2.2 and the same 9.6 drivers released a couple weeks ago. I checked both blackmagicdesign.com and blackmagic-design.com. I also tried the link on the front pages of those sites, but no luck. I'm hoping for 650M support in Resolve as I can't get it to run in Mountain Lion on my Retina MBP when I tested it last week.
